TP-link Archer MR600 4G+ Cat6 AC1200 Router

TP-Link Archer MR600 4G+ Cat6 AC1200 Router is a high-performance networking solution designed to provide fast and reliable internet access without the need for a fixed broadband line. With support for 4G+ Cat6 technology, this router delivers download speeds of up to 300 Mbps, ensuring smooth HD streaming, online gaming, and video conferencing. Its dual-band Wi-Fi offers combined speeds up to 1200 Mbps, while full gigabit ports ensure stable wired connections for bandwidth-intensive devices. The Archer MR600 also supports TP-Link OneMesh, allowing seamless whole-home coverage when paired with compatible range extenders.

Product Features

4G+ Cat6 Technology

Utilizes carrier aggregation to boost 4G+ speeds up to 300 Mbps, offering faster and more stable mobile internet connectivity.

Dual-Band Wi-Fi

Provides combined wireless speeds of up to 1200 Mbps, with 867 Mbps on 5 GHz for high-performance tasks and 300 Mbps on 2.4 GHz for everyday browsing.

Full Gigabit Ports

Features four Gigabit LAN ports and one Gigabit WAN/LAN port for high-speed wired connections to PCs, smart TVs, and gaming consoles.

Plug and Play SIM Slot

Simply insert a micro SIM card and enjoy instant internet access without complex configurations.

OneMesh Support

Compatible with TP-Link OneMesh range extenders, enabling a seamless, unified Wi-Fi network across your home.

Stable Coverage with Antennas

Equipped with two detachable LTE antennas and four internal Wi-Fi antennas for strong and stable connectivity throughout your space.

Easy Setup and Management

The TP-Link Tether app makes installation and network management simple, giving you full control over your router from your smartphone.

​Product specifications

Hardware Features:

• Interfaces:
  • 1 × Gigabit WAN/LAN port​
  • 3 × Gigabit LAN ports​
  • 1 × Nano SIM card slot​
• Buttons:
  • WPS/Reset button​
  • Wi-Fi On/Off button​
  • Power On/Off button​
• Power Supply:
  • Input: 100-240V~50/60 Hz 0.6A​
  • Output: 12V ⎓ 1.5A​
• Antenna:
  • 2 × detachable 4G LTE antennas​
• Dimensions:
  • 202 × 141 × 33.6 mm (7.95 × 5.55 × 1.32 in)​

Wireless Features:

• Wireless Standards:
  • IEEE 802.11a/n/ac (5 GHz)​
  • IEEE 802.11b/g/n (2.4 GHz)​
• Frequency:
  • 2.4 GHz and 5 GHz​
• Signal Rate:
  • 2.4 GHz: up to 300 Mbps
  • 5 GHz: up to 867 Mbps​
• Reception Sensitivity:
  • 5 GHz:
    • 11a 54M: -74 dBm
    • 11ac HT20: -66 dBm
    • 11ac HT40: -63 dBm
    • 11ac HT80: -59 dBm
    • 11n HT20: -73 dBm
    • 11n HT40: -70 dBm
  • 2.4 GHz:
    • 11g 54M: -74 dBm
    • 11n HT20: -72 dBm
    • 11n HT40: -69 dBm
• Transmit Power:
  • < 20 dBm (2.4 GHz)​
  • < 23 dBm (5 GHz)​
• Wireless Functions:
  • Enable/Disable Wireless Radio​
  • Wireless Schedule​
  • WMM​
  • Wireless Statistics​
• Wireless Security:
  • 64/128-bit WEP​
  • WPA/WPA2, WPA-PSK/WPA2-PSK encryptions​

Network Type:

• 4G:
  • FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)​
  • TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)​
• 3G:
  • DC-HSPA+/HSPA/UMTS: B1/B5/B8 (2100/850/900 MHz)​

Carrier Aggregation:B1+ B5/B7/B8/B20​

• B3+B3/B5/B7/B8/B20/B28/B38/B40​
• B5+B5/B7/B40​
• B7+B7/B8/B20/B28​
• B28+B40​
• B38+B38​
• B40+B40​
• B41+B41​

Software Features:

• Quality of Service (QoS):
  • Bandwidth Control​
• Security:
  • DoS
  • IPv4 SPI Firewall​
  • IPv6 Firewall
  • IP and MAC Address Binding​
  • Access Control​
• WAN Type:
  • Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)​
• Management:
  • TP-Link Cloud​
  • Local Management​
  • Remote Management​
• DHCP:
  • Server​
  • DHCP Client List​
  • Address Reservation​
• Port Forwarding:
  • ALG​
  • Virtual Server​
  • Port Triggering​
  • UPnP​
  • DMZ​
• Dynamic DNS:
  • TP-Link​
  • DynDns​
  • NO-IP​
• VPN:
  • PPTP VPN​
  • IPSec VPN​
  • OpenVPN
